EATON MEDIUM-SPEED MOTOR
Hydrokit Part Number : MHP100A1AE
Discontinued product replaced by :
Motor WP 100cc shaft Ø25mm ( MHP100A1AW )
Technical information
EATON MEDIUM-SPEED MOTOR
- Displacement: 97.9cc
- Flange: SAE A, Ø82.55 centring, Ø106.4mm alignment
- Shaft: Cylindrical, Ø25mm, reinforced seal
- Ports: 1/2"BSP - 1/4" BSP (drain)
- Paint: Black
- Displacement: 97.9cc
- Flange: SAE A, Ø82.55 centring, Ø106.4mm alignment
- Shaft: Cylindrical, Ø25mm, reinforced seal
- Ports: 1/2"BSP - 1/4" BSP (drain)
- Paint: Black
Technical data
| Motor type | OMP Gerotor |  |
|
| Displacement | 100 | cc/rev | |
| Flange type | SAE A flange |  |
|
| Shaft type | Cylindrical |  |
|
| Size of the shaft | 25 mm | ||
| Orifices position | Side port - Offset |  |
|
| Orifices A & B size | G1/2 | ||
| Taille du drain | G1/4 | ||
| Bearing type | Journal bearing | ||
| Speed sensor (predisposition) | No | ||
| Paint | Black RAL 9005 | ||
| Marque | Danfoss (ex Eaton Charlynn) |  |
