DANFOSS OMSS MOTOR 160CC
Hydrokit Part Number : MHSS16000
Technical information
DANFOSS OMSS MOTOR 160CC (159.7cm3)
Shaft: splined 12 teeth 12/24 Pitch Ø27.6mm
Flange: short 4 holes Ø125mm Ø99.9m centring
Ports: 1/2 BSP (A & B) 1/4 BSP (D)
Geniune Danfoss reference: 151F0538
Shaft: splined 12 teeth 12/24 Pitch Ø27.6mm
Flange: short 4 holes Ø125mm Ø99.9m centring
Ports: 1/2 BSP (A & B) 1/4 BSP (D)
Geniune Danfoss reference: 151F0538
Technical data
| Motor type | OMSS |  |
|
| Displacement | 160 | cc/rev | |
| Shaft type | Splined |  |
|
| Size of the shaft | 12 dents 12/24 | ||
| Orifices position | Side port - Offset |  |
|
| Orifices A & B size | G1/2 | ||
| Taille du drain | G1/4 | ||
| Bearing type | Sans roulement - Bearingless | ||
| Speed sensor (predisposition) | No | ||
| Paint | Not paint | ||
| Marque | Danfoss / White WDMS |  |
