Additional info Trailer brake valve 14mm piston Compatible with mineral oil Ports M22x150 (Pilot M12 x 150) Max pressure 220 bar Flow rate 20 - 100 lpm Piston 14mm dia - volume 0.6cm3 - pilot ratio 5.4 TRAILER BRAKE VALVE 14MM PISTON 203273MN14
Additional info Compatible mineral oil Ports M22x150(control M12x150) Max pressure 220bar Flow rate 20-100 L/min Controlpiston Ø22 - volume 1.8 cm3 - pressureratio 13.4 Piston trailer brake valve Ø22 - mi 203273MN22
Additional info SAFIM TRAILER BRAKE VALVE - Ssuitable for DOT 3-4 - Lockheed synthetic oil - Piston diameter: Ø10mm - Pressure ratio: 1/2.8 - Max. volume: 0.4cc - Max. pressure: 220bar - Max. flow rate: 20-100lpm - Ports: M22x150 and M12x150 (pilot) SAFIM TRAILER BRAKE VALVE 203273FN10
Additional info SAFIM TRAILER BRAKE VALVE - Ssuitable for DOT 3-4 - Lockheed synthetic oil - Piston diameter: Ø14mm - Pressure ratio: 1/5.4 - Max. volume: 0.6cc - Max. pressure: 220bar - Max. flow rate: 20-100lpm - Ports: M22x150 and M12x150 (pilot) SAFIM TRAILER BRAKE VALVE 203273FN14
Additional info Trailer brake valve 10mm piston Compatible with mineral oil Ports M22x150 (Pilot M12 x 150) Max pressure 220 bar Flow rate 20 - 100 lpm Piston 10mm dia - volume 0.4cm3 - pilot ratio 2.8 TRAILER BRAKE VALVE 10MM PISTON 203273MN10
Additional info Compatible mineral oil. Ports M22x150(control M12x150) Max pressure 220bar. Flow rate 20-100 L/min. Controlpiston Ø20 - volume 1.5cm3 - pressureratio 11.1 Piston trailer brake valve ø20 - mi 203273MN20
Additional info SAFIM TRAILER BRAKE VALVE - Ssuitable for DOT 3-4 - Lockheed synthetic oil - Piston diameter: Ø20mm - Pressure ratio: 1/11.1 - Max. volume: 1.5cc - Max. pressure: 220bar - Max. flow rate: 20-100lpm - Ports: M22x150 and M12x150 (pilot) SAFIM TRAILER BRAKE VALVE 203273FN20
Additional info SAFIM TRAILER BRAKE VALVE - Ssuitable for DOT 3-4 - Lockheed synthetic oil - Piston diameter: Ø10mm - Pressure ratio: 1/2.8 - Max. volume: 0.4cc - Max. pressure: 220bar - Max. flow rate: 20-100lpm - Ports: M22x150 and M12x150 (pilot) SAFIM TRAILER BRAKE VALVE 203273FN12
