Quick-release fasteners hydraulic control unit and housing
To power and control a hydraulic attachment from the cab
- CE-approved hydraulic control unit
- Control box according to the fastener control standard
- Incorporates bucket pressure control function
- 1 single 12/24 VDC box for all attachments (single/double acting - with/without pressure switch)
The kit includes:
- CE universal in-cab control unit
- 12-24 Volt harness
- Adjusted hydraulic block with pressure tap
- Connections: Pressure and return connections by brand, Hoses by machine tonnage and Dipperstick end supports
- Visual and audio self-diagnosis
Ask also for our specific kits per machine with supports and instructions visual and audio self-diagnosis
Operation and features
-
To unhook an equipment: press the 2 red buttons. The 2 red lights will light up and a buzzer will sound: the attachment is unlocked Operation and features
-
To attach equipment: press the green button. The green light comes on and the beeper stops: the attachment is locked
Technical specifications
-
Even more compact case, delivered with its stand
-
Safe, ergonomic push-button operation with visual and acoustic control
-
Harness with DEUTSCH sockets: 4 variants according to block diagram
-
Hose kit depending on tonnage, single or double acting cylinder
-
Hydraulic block depending on the type of attachment
